1. This equipment is a high-precision device developed specifically for glucose test strips after printing, featuring an added punching function for long-distance blood absorption channels.
2. The equipment adopts hole positioning, manual feeding, automatic punching, automatic waste collection, and automatic finished product collection. It serves as an ideal production auxiliary device for manufacturing enterprises.
3. Custom molds can be produced according to different requirements, with a minimum aperture of 0.8 mm, capable of forming 50 pieces in a single operation. The equipment can optionally incorporate a CCD detection function to automatically identify punching positions and measure punching dimensions.
4. The molds utilize imported Japanese SKD-61 alloy material combined with vacuum heat treatment, offering excellent wear resistance. Custom surface titanium coating treatment is also available.
